概述

简介

android轨迹SDK是一套轨迹服务应用程序接口。您可以开发适用于移动设备的轨迹追踪应用，实现实时轨迹追踪、轨迹上报、历史轨迹查询、地理围栏报警等功能。

功能介绍及体验

轨迹上报

使用GPS、基站或Wi-Fi信息，实现室外连续轨迹记录及上报

    //轨迹上报
    /**
     * 轨迹服务
     */
    protected static Trace trace = null;

    /**
     * entity标识
     */
    protected static String entityName = null;

    /**
     * 服务ID，开发者创建的服务对应的服务ID
     */
    protected static long serviceId = xxx; // serviceId为开发者创建的服务ID

    /**
     * 轨迹服务类型（0 : 不建立soket长连接， 1 : 建立socket长连接但不上传位置数据，2 : 建立socket长连接并上传位置数据） 3: http连接
     */
    private int traceType = 3;


    // 初始化轨迹服务
    trace = new Trace(getApplicationContext(), serviceId, entityName,
            traceType);

  /**
     * 开启轨迹服务
     */
    private void startTrace() {
        // 通过轨迹服务客户端client开启轨迹服务
        MainActivity.client.startTrace(trace, startTraceListener);
    }


     /**
     * 回调OnStartTraceListener
     */
    private void initOnStartTraceListener() {
        // 初始化startTraceListener
        startTraceListener = new OnStartTraceListener() {

            // 开启轨迹服务回调接口（arg0 : 消息编码，arg1 : 消息内容，详情查看类参考）
            public void onTraceCallback(int arg0, String arg1) {
                Log.e("服务开启",arg1);

            }
        };
    }

轨迹查询

实时查询实体轨迹及查询实体某段时间的历史轨迹

    //轨迹查询
        TrackRequest trackRequest = new TrackRequest();
        trackRequest.setEntity_name(MainActivity.entityName);
        trackRequest.setService_id(String.valueOf(MainActivity.serviceId));
        trackRequest.setStart_time(String.valueOf(startTime));
        trackRequest.setEnd_time(String.valueOf(endTime));
        trackRequest.setPage_index(pageIndex);
        trackRequest.setPage_size(pageSize);
        MainActivity.client.queryHistory(trackRequest,trackListener);


        trackListener = new OnTrackListener() {
            @Override
            public void onRequestSucessCallback(String result) {

            }
            @Override
            public void onQueryHistoryTrackCallback(TrackResult result) {


            }
        };
    }

地理围栏

地理围栏是指一定范围的虚拟地理区域。当被追踪者进入、离开该区域时，会有相应的报警提示

//地理围栏
    1.围栏创建
        Fence fence = new Fence();
        fence.setServiceId(serviceId);
        fence.setFenceName(entityName+"_fence");
        fence.setFenceDesc("test");
        fence.setCreator(entityName);
        fence.setMonitoredPersons(entityName);
        fence.setValidTimes("0800,2300");
        fence.setValidCycle(4);
        fence.setValidDate("");
        fence.setValidDays("");
        fence.setShape(1);
        fence.setCoordType(3);
        fence.setCenter(longitude + "," + latitude);
        fence.setRadius(radius);
        fence.setCoordStr("");
        fence.setAlarmCondition(3);
        client.createFence(fence,
                geoFenceListener);
    2.围栏更新
        Fence fence = new Fence();
        fence.setServiceId(serviceId);
        fence.setFenceName(entityName+"_fence");
        fence.setFenceDesc("test");
        fence.setCreator(entityName);
        fence.setMonitoredPersons(entityName);
        fence.setValidTimes("0800,2300");
        fence.setValidCycle(4);
        fence.setValidDate("");
        fence.setValidDays("");
        fence.setShape(1);
        fence.setCoordType(3);
        fence.setCenter(longitude + "," + latitude);
        fence.setRadius(Geofence.radius);
        fence.setCoordStr("");
        fence.setAlarmCondition(3);
        //and create diff
        fence.setObservers("");
        fence.setFenceId(String.valueOf(fenceId));
        client.updateFence(fence,
                geoFenceListener);
    3.围栏查询
         // 创建者（entity标识）
        String creator = entityName;
        // 围栏ID列表
        String fenceIds = "1，2，3";
        MainActivity.client.getListFence(serviceId, creator, fenceIds, geoFenceListener);

    /**
     * OnGeoFenceListener 围栏回调
     */
    private void initOnGeoFenceListener() {
        // 初始化geoFenceListener
        geoFenceListener = new OnGeoFenceListener() {
            @Override
            public void onRequestFailedCallback(Result result) {

            }

            @Override
            public void onCreateCircularFenceCallback(FenceCreateResult result) {


            }

            @Override
            public void onUpdateFenceCallback(Result result) {

            }

            // 查询历史报警回调接口
            @Override
            public void onQueryHistoryAlarmCallback(Result result) {

            }
        };
    }
